Door detailing

Door detailing machines and inserting systems

LEHRBINK manufactures machines for the complete processing of doors. Depending on the equipment the machines can carry out the complete routing and drilling on a door leaf: Whether hinges, notch hinges or concealed hinges, whether lock cases, hinge milling, handle holes or lock cylinders – all these processings can be done on LEHBRINK machines.
The machines can be designed for small, middle or big quantities, so that the demands on different batch sizes can be provided.

TBZ 510 - Door detailing machines

NC-controlled door processing center for drilling and milling.

TBZ 510 - Door detailing machines

The CNC-controlled door processing centre executes all drilling and milling work for a variety of door hardware on the lock, hinge and transverse side, as well as the surface for light cut out routing etc.

The processing positions are freely selectable at all longitudinal and transverse edges, as well as door surfaces. They are approached with the highest precision through the CNC-controlled axes.

Processings:

  • Bolt drilling
  • Milling for ID-plate
  • Hinge milling
  • Drilling for screw in hinges
  • Face machining for lock
  • Face machining for cylinder lock
  • Lock face milling
  • Lock plate fastening holes
  • Special lock milling
  • Lock plate millingPivot milling
  • Hinge mounting
  • Deep mortise machining
  • Milling for light opening
  • Providing the door with a single or double rebate

For further information please contact our Lehbrink Sales Team:

Phone: +49 (0) 5202-990 510
e-Mail: info(at)lehbrink.com

CNC-controlled machining center with 2 processing spindles. The machining positions are freely selectable at the longitudinal and transverse edge as well as the surface.
Drilling and shaping Station for the most varied processings at the edge and on the surface.

Door leaf processing - single or double-sided

Shaping Station from above and below for handle holes and lock cylinders

Automated assembly of locking plates, hinge pockets etc.

Hinge pocket magazine for the automatic feeding of the fitting unit
